XHS-C系列
撓性聯軸器 - 單膜片型
Single Disk-type Flexible Coupling
●所有產品均附帶內六角止動螺絲。
●適用軸徑的*尺寸容許偏差為h6及h7。
●安裝到D型切口軸時，請注意軸的D型切口面的位置。
●可對軸孔和鍵槽進行追加工。請使用追加工服務。
材質、表面處理
XHS
軸套 A2017
陽極氧化處理
固定膜片螺栓 SCM435
四氧化三鐵保護膜（黑）
膜片 SUS304
軸環 SUS304
內六角螺栓 SCM435
四氧化三鐵保護膜（黑）
構造
夾緊型XHS-C
XHS-C短巧型
XHS結構
特點
適用馬達
XHS
伺服馬達 ◎
步進馬達 ◎
通用馬達 ◎
◎：特優 ○：優
特性
XHS
零背隙 ◎
適用于高增益 ○
高扭矩 ◎
高扭轉剛性 ◎
容許誤差調整 ○
◎：特優 ○：優
單膜片型的撓性聯軸器。
額定扭矩為傳統產品的1.5倍，為高扭矩規格。
zui適用于瞬間zui大扭矩達350%的伺服馬達。
不銹鋼膜片聯軸器可容許偏心、偏角及軸向偏差。
用途
引動器/表面封裝機/精密XY軸滑臺/分度臺
相關服務
無塵洗凈、無塵包裝服務
聯軸器 軸孔、鍵槽追加加工服務
型號列表
